GEM-P816 Programming Instructions
Page 16
NAPCO Security Systems
R
SYSTEM OUTPUT TIMEOUTS (ADDRESS 1412 & 1414-1416)
1. Select delay/timeout (0-255 min.) from the table shown.
2. Enter in corresponding address locations above.
3. Press U to save.
OUTPUT TIMEOUTS: If a timeout of “0 min.” is selected, then the output will remain active (ON)
until the system is reset or disarmed. For UL Residential Installations, the minimum timeout is 4
minutes. Not UL listed for Commercial Installations.
DOWNLOAD/CALLBACK OPTIONS (ADDRESS 2059 & 0526-0545)
NUMBER OF RINGS BEFORE PICKUP: Enter the number of rings before automatic
pickup by the control panel when downloading from a computer (see Glossary at the back
for more information).
1. Enter digit only.
2. Valid entries are: 003-015. NOTE: Default is 15 Rings.
3. Press U to save.
CALLBACK TELEPHONE NUMBER: Enter telephone number to be used when downloading from a computer (see Glossary at
the back for more information).
1. Enter digit only (right nibble).
2. Enter up to 20 digits from left to right. NOTE: Leave trailing boxes blank (•).
3. Valid entries are: 1-9, B = *button, C = #button, D = 3 sec. pause, E = Wait for dial tone, F = ignore location.
4. Press U to save.
PAGER FORMAT OPTIONS (ADDRESS 0546 & 0547)
LEADING DIGITS FOR PAGER FORMAT: In Pager Format reporting, the message typically begins with “00”.
However, for some pager services, this will cause the Pager's Voice Mail feature to activate. This option allows
you to program these digits to any number desired. A typical Pager report is “003 22 1234”, where 3 is the Event,
22 is the zone, and 1234 is the Subscriber ID number. For example, if the Leading Digits are programmed as “98”,
the Pager report will now appear as “983 22 1234”.
NOTE: See CS Receiver Options to select Pager Format.
1. Enter in 1st and 2nd Leading Digits as shown (right nibble).
2. Valid entries are: 0-9. Press U to save.
Callback
Telephone
Number
ADDRESS 0526-0545 (RIGHT DIGITS 1-20)
0526 0527 0528 0529 0530 0531 0532 0533 0534 0535 0536 0537 0538 0539 0540 0541 0542 0543 0544 0545
(Digits 1-20)
[Default = blank (•) for all digits 1-20]
No. Rings
ADDRESS 2059
Before
Pickup
[Default = 015 ]
PGM2
ADDRESS 1412
Output
Timeout (min.)
[Default = 0 min. = blank (•)]
Alarm
ADDRESS 1414
Output
Timeout (min.)
[Default = 015]
Pulse Alarm
ADDRESS 1415
Output
Timeout (min.)
[Default = 015]
PGM1
ADDRESS 1416
Output
Timeout (min.)
[Default = 0 min. = blank (•)]
DELAY/
TIMEOUT
blank (•) 0 min.
001 1 min.
002 2 min.
003 3 min.
004 4 min.
005 5 min.
006 6 min.
016 16 min.
255 255 min.
DATA
ENTRIES
Leading Digits for
ADDRESS 0546
Pager Format
(1st Digit)
Leading Digits for
ADDRESS 0547
Pager Format
(2nd Digit)
[Default = blank (•) blank (•)]
To Next Page
