GEM-P816 Programming Instructions

Page 27
Enable Keypad Options
Enable Keypad Options
ADDR
Keypad
Fire
Keypad
Aux.
‡
Keypad
Panic
RSRVD Ambush
Easy
Arming
Panel
Access
RSRVD
1 2 3 4 5 6 7 8
Keypad 1 Options
1440
Keypad 2 Options
1441
Keypad 3 Options
1442
Keypad 4 Options
1443
Keypad 5 Options
1444
Keypad 6 Options
1445
Keypad 7 Options
1446
[Default = blank (•) from address 1440-1446]
‡
NOTE: Keypad Aux. is not to be selected for UL Installations.
KEYPAD OPTIONS (ADDRESS 1425-1431, 1440-1446)
Enable Keypad Type
& Activation
Enable Keypad Type Keypad Area Assignment
KEYPAD TYPE: Up to 7 key-
pads may be programmed, if
they are connected.
NOTE: See Keypad Configura-
tion Mode.
1.
Select keypad type for each
keypad from the tables
shown.
2.
Enter data in corresponding
address locations.
3.
Press U to save.
ADDR
Blank (•) = Burg Keypad
2 = Wizard
‡
‡
Not for UL Installations
Blank (•) = Disabled
1 = Area 1
Keypad 1
1425
Keypad 2
1426
Keypad 3
1427
Keypad 4
1428
Keypad 5
1429
Keypad 6
1430
Keypad 7
1431
[Default = blank (•) from address 1425-1431
ENABLE KEYPAD OPTIONS: Select options for any of the 7 keypads.
 1. Select the desired option entering the option number (1-8) for each digit.
 2. At the keypad, enter corresponding option number in address location.
NOTE: Dark shaded data value box shows option not available.
 3. Press U to save.
