GEM-P816 Programming Instructions

Page 29
ZONE OPTIONS - ZONES 1 TO 16 (ADDRESS 0900-1016)
ZONES 1  8 ZONES 9  16
ZONE OPTIONS ADDR Z1 Z2 Z3 Z4 Z5 Z6 Z7 Z8 ADDR Z9 Z10 Z11 Z12 Z13 Z14 Z15 Z16
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
50ms Loop Response (A) 0900 0964

Priority 0901 0965
Priority with Bypass 0902 0966
Auto-Bypass 0903 0967

Selective Bypass 0904 0968
Keyswitch Arming 0905 0969
Auto-Bypass Re-entry 0906 0970
Pre-Alarm Warning 0907 0971
Never Arm 0908 0972
24-Hour Zone 0909 0973

Alarm Output 0910 0974

Pulsed Alarm Output 0911 0975
PGM1 Output 0912 0976
PGM2 Output 0913 0977

Entry/Exit 1 0914 0978
Entry/Exit 2 0915 0979

Exit/Entry Follower 0916 0980

Auto Reset 0917 0981

Swinger Shutdown 0918 0982

Chime 0919 0983
Abort Delay 0920 0984
Power-up Delay 0921 0985
Day Zone Open 0922 0986
Day Zone Short 0923 0987
Alarm on Day Zone 0924 0988

Alarm Telco 1 0925 0989
Alarm Restore 1 0926 0990
Trouble Telco 1 0927 0991
Trouble Restore 1 0928 0992
Alarm Telco 3 0929 0993
Alarm Restore 3 0930 0994
Trouble Telco 3 0931 0995
Trouble Restore 3 0932 0996
No EOL Resistor 0933 0997
Trouble on Open 0934 0998
Trouble on Short 0935 0999

Zone Area 1 0936 1000
RESERVED 0937 1001
RESERVED 0938 1002
Keypad Sounder on Alarm 0941 1005

2-Wire Smoke Detectors (B) 0942 1006

Fire (C) 0943 1007
Fire Alarm Verification (C) 0944 1008
RESERVED 0945 1009
Zone ANDing Group 1 0946 1010
Zone ANDing Group 2 0947 1011
Zone ANDing Group 3 0948 1012
Zone ANDing Group 4 0949 1013
Sensor Watch 0950 1014
RESERVED 0951 1015
Chime 2 0952 1016
 When the Easy Program Menu is used, these features are enabled by default.
 Enabled when "Enable SIA CP-01 Features?" is activated (Answer "Yes" in the EZ Programming Menu).
 Disabled when "Enable SIA CP-01 Features?" is activated (Answer "Yes" in the EZ Programming Menu). Disable Auto-Reset on non-fire zones for SIA CP-01 installations.
Interior (Stay) Bypass 0940 1004
RESERVED 0939 1003
RESERVED 0953 1017
RESERVED 0954 1018
ZONE OPTIONS: Select zone options for any zone.
 1. Select the desired zone option by entering the option number (1-8) for each selected zone.
 2. Enter corresponding option number in address location.
NOTE: Dark shaded data value box shows option not available. Press [Enter] to save.
Notes A, B and C are
located on the next
page.
