GEM-P816 Programming Instructions
Page 8
NAPCO Security Systems
R
Enable Burg Output Chirp on Keyfob?
• Press the NEXT/YES button to enable Burg Output Chirp on Keyfob Arm / Disarm.
• Press the PRIOR/NO button to continue.
NOTE: The Burg Output will chirp once on Keyfob Arm and twice on Keyfob Disarm.
Enable SIA CP-01 Features?
• Press the NEXT/YES button to enable.
• Press the PRIOR/NO button to continue.
The SIA CP-01 Features are designed to reduce the incidence of false alarms. NOTE: Do not
enable unless reporting, otherwise system trouble Fail to Communicate may occur.
Number of Keypads in Area 1
• Enter the total number of Keypads to be installed in Area 1.
• Valid entries are from 01 to 07. Directly enter the number of keypads, including leading zeros.
Press U to save. Press the NEXT/YES button to proceed.
Central Station Receiver 1 Telephone Number
• Enter telephone number of up to 16 digits.
• Press 1 through 9 for digits 1–9; G 0 for a zero and 0 for a blank (•).
• Press G 1 through G 5 for letters B–F, respectively.
• Pre-Dial Delay = “D” (G 4); Dial-Tone Detection = “E” (G 5).
• Press U to save and press the NEXT/YES button to proceed.
NOTE: Central Station Receiver 2 and 3 Telephone Numbers must be entered in Direct Ad-
dress Programming. See CS Receiver Options.
Central Station Receiver 1 Account Number
• Enter an account number of up to four digits.
• Press 0 through 9 for digits 0–9, and G 0 for a blank (•).
• Press U to save and press the NEXT/YES button to proceed.
NOTE: Central Station Receiver 2 and 3 Account Numbers
must be entered in Direct Address Programming. See CS
Reporting Options.
Central Station Receiver 1 Format
• From the table at the right enter the receiver format.
• Press 0 through 9, and G0 for blank (•).
• Press G1 through G4 for letters B–E.
• Press U to save; press the NEXT/YES button to proceed.
Enter User Codes (Press R to set cursor.)
For default program, enter up to 16 User Codes, with Area 1 Options.
• Press the (R) button once to set the cursor to the User Code.
• Press 0 through 9 to enter a code from 3 to 6 digits, leave blank (•) any trailing boxes.
• Press R to set the cursor to the Area 1 Options Level. Refer to the table below for available
options.
• If “Enable Global Ambush Code” (Address 1422) is enabled and “Global Ambush Code” (Address 2045) is not left blank (•), do not program the
first two digits of ANY User Code the same as the “Global Ambush Code”. See Address 2045 further in this manual for more information.
• Press U to save. Note: Duplicate User Codes are not allowed; therefore a duplicate Code entered in the LCD Window will erase when U is
pressed. To proceed to the next User Code, press R to set the cursor to the User Number and change it using the number buttons. Press
the NEXT/YES button to proceed.
(Direct Entry)
Central Phone #
(Direct Entry)
Central Station
Account # (____)
DATA
ENTRY
CS RECEIVER 1 FORMAT
•
(blank)
Ademco Slow, Silent Knight
Slow
2 Radionics Fast
3 Silent Knight Fast
4 Radionics, DCI, Franklin Slow
5 Universal High Speed
B SIA
C Ademco Point ID
E Pager
(Direct Entry)
See WI for Info
Rcvr Format (0)
Enter user code->
U01 123 - 9-
User# User Code Area 1
Example: Program a code of “2222” for user
02, with area 1 options of “Arm/Disarm” and
“User Program”. Enter “2222” for a user code,
“• (blank) 9” for area 1 options.
(Direct Entry)
# Area 1 Keypads
Enter # KPs 01
(Press YES or NO)
Enable SIA CP-01?
Y/N
(Press YES or NO)
Enable Burg Out
Chirp? Y/N
USER AREA OPTIONS
DATA ENTRIES
L R
blank(•) blank(•) Disabled
blank(•) 1 Arm/Disarm
blank(•) 2 Arm Only
blank(•) 3 Service
blank(•) 4 Access
blank(•) 5 Ambush
blank(•) Add 8 * User Program
4 blank(•) Bypass Enable
OPTION
ENABLED
USER OPTIONS
USER CODE
(UP TO 6 DIGITS)
AREA 1
OPTIONS
To Next Page
