GEM-P816 Programming Instructions

Page 23
Default for Group Zone Report Codes depends on Easy Menu Question “RCVR. FORMAT”.
CS ZONE REPORTING OPTIONS (ADDRESS 0720-0735)
ADDRESS 0720-0727
CONTROL PANEL ZONES REPORT CODE
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 5 ZONE 6 ZONE 7 ZONE 8
0720 0721 0722 0723 0724 0725 0726 0727
ADDRESS 0728-0731
ZONES REPORT CODE
ZONE 9 ZONE 10 ZONE 11 ZONE 12
0728 0729 0730 0731
ADDRESS 0732-0735
ZONES REPORT CODE
ZONE 13 ZONE 14 ZONE 15 ZONE 16
0732 0733 0734 0735
PULSE EVENT CODE will be the first digit of the 2 digit reporting code. The second digit will be the
second digit of the reporting zone. For example, for zone 9 (address 0728), if the right digit is “3", then
the reporting code is ”39". For example, for zone 15 (address 0734), if the right digit is “4", then the
reporting code is ”45".
MODEM CODES determine the zone types reported for the following formats: SIA and ADEMCO Point ID.
 1. Select the desired Modem Code for each zone from the table shown.
 2. Press U to save.
ZONE REPORT
CODE OPTIONS
DATA ENTRIES
DATA
ENTRIES MODEM CODE
LEFT
1 Fire
2 Panic
3 Burglary
4 Hold up
7 Gas Alarm
8 Heat Alarm
0 Auxiliary Alarm
B 24 Hour Auxiliary
