Appendix A Device-Specific Information
NI USB-621x User Manual A-22 ni.com
Figure A-14. USB-6218 BNC Top Panel and Pinout
NI USB-6218
AI x +
AI x –
GS
0.1 µF
5 kΩ
AI GND
FS
+
–
USB-621x Device
Floating
Source
AI x +
AI x –
GS
0.1 µF
5 kΩ
AI GND
FS
+
–
USB-621x Device
Ground-
Referenced
Source
