StockCode:
NARF80A
Page 23 of 51
Description
:
Final Assy, VX1.5/2,
Component Lvl, StockCode Reference DesignationDescription
LS62
02
Inductor, SMT, Power, 3.6uH, 8.2A, Shielded L28
LS63
02
Inductor, SMT, Power, 2.2uH, 8Arms, Shielded L29
LS64
02
Inductor, SMT, Power, 12uH, 2.2Arms, Shielded L02, L17, L25
LS65
02
Inductor, SMT, 470nH, 550mArms, 5%, 0603 L08
LS75
02
Inductor, SMT, 2.2uH, 2.4A, Shielded L11
QDLS01
02
Diode, SMT, LED, Green, (560nm), 0603 DS01
QDLS03
02
Diode, SMT, LED, Red, (660nm), 0603 DS02
QDRS01
02
Diode,SMT,Switching,250V,0.2A, SOD-323 CR01, CR07, CR18, CR19, CR20, CR21, CR22, CR23, CR24
QDSS01
02
Diode, SMT, Schottky, 30V, 0.2A, SOD-323 CR08, CR09, CR10
QN53
02
Transistor,SMT,MOSFET,N-Channel, 60v,115mA,SOT-23 Q01, Q02, Q03, Q04, Q05,
QR70
02
Suppressor, Transient Voltage, SMT 60V Clamp
CR04, CR05, CR06, CR11, CR12, CR15, CR16, CR17, CR25,
CR26
QR82
02
Diode, SMT, TVS, Vw 5V, Vb 6V Vc 10.8V, SOT-143 CR02, CR03, CR13, CR14
QS32
02
Transistor, SMT, Dual N-CH MOSFET, 20V, 10A, SO-8
U68
RAE34
02
Resistor,SMT,MF,49.9R,1%,1/10W 0603 R363, R365, R370, R371
RAF01
02
Resistor SMT MF 0.0 Ohm Jumper 0402
R051, R129, R144, R147, R156, R161, R225, R230, R241,
R264, R268, R320, R328, R349, R350,, R385, R409, R410
RAF10
02
Resistor SMT MF 4.75 Ohm 1% 1/16W 0402 R005, R006, R012, R013
RAF20
02
Resistor SMT MF 33.2 Ohm 1% 1/16W 0402
R062, R075, R076, R087, R138, R191, R196, R197, R200,
R204, R237, R238, R244, R247, R297, R303,, R321, R325,
R326, R327, R390, R391, R392, R397, R416, R417
RAF26
02
Resistor SMT MF 100 Ohm 1% 1/16W 0402
R033, R049, R052, R094, R098, R108, R109, R133, R330,
R332, R415
RAF27
02
Resistor SMT MF 121 Ohm 1% 1/16W 0402 R158, R206, R207, R217, R218
RAF28
02
Resistor SMT MF 150 Ohm 1% 1/16W 0402 R393, R394, R395, R396
RAF32
02
Resistor SMT MF 332 Ohm 1% 1/16W 0402 R026, R219
RAF34
02
Resistor SMT MF 475 Ohm 1% 1/16W 0402
R025, R034, R139, R140, R142, R143, R171, R208, R221,
R373, R375, R376
RAF35
02
Resistor SMT MF 562 Ohm 1% 1/16W 0402 R152
RAF38
02
Resistor SMT MF 1000 Ohm 1% 1/16W 0402
R040, R060, R092, R096, R099, R100, R104, R121, R124,
R130, R134, R149, R163, R176, R227, R234,, R266, R267,
R309, R311, R338, R339, R340, R341, R377, R401
RAF40
02
Resistor SMT MF 1500 Ohm 1% 1/16W 0402 R164, R186, R187, R259, R272, R275, R318, R324, R372
RAF42
02
Resistor SMT MF 2210 Ohm 1% 1/16W 0402
R068, R072, R074, R078, R079, R080, R081, R131, R136,
R137, R145, R150, R159, R166, R168, R172,, R174, R177,
R178, R181, R253, R322, R323, R357, R358, R361, R364,
R366, R367, R369, R374
