VX150 TO VX2 TROUBLESHOOTING MANUAL WIRING INFORMATION
VERSION 2.0 2023-04-20 PAGE 3.3.1
SECTION 3.3: WIRING INFORMATION
This section contains the wiring information for the transmitter, and applicable connector mating
information.
Wiring Lists Provided
Wiring lists are provided in tabular format. Table 3.3.1 on page 3-1 lists the tables containing wiring and
cable information. These tables provide non-printed wiring pattern, point-to-point (source and
destination) interconnection information.
Connector Mating Information
Where applicable, connector mating information is included with the associated wiring list. See the
Source Mate and Destination Mate columns in Table 3.3.4 and Table 3.3.5.
Wire Colours
Every effort is made to manufacture assemblies using the wire colour shown in the Colour column of
the wiring list tables. Sometimes, a white wire will be substituted for the listed colour. In such cases,
wires must be identified by their assigned numbers.
Printed Wiring Board Patterns
Printed wiring pattern information for printed wiring boards (PWBs) is beyond the scope of this manual,
and therefore not provided.
Table 3.3.1: Wiring Lists Provided
TABLE #
Description
Table 3.3.2
Wiring List - Wire Kit 1 PA (235-8102), VX150/VX300/VX600 and VX1 (page 3.3.2)
Table 3.3.3
Wiring List - Wire Kit 2 PA (235-8202), VX1.5/VX2 (page 3.3.2)
Table 3.3.4
Wiring List - Cable Information, VX150/VX300/VX600 and VX1 (page 3.3.2)
Table 3.3.5
Wiring List - Cable Information, VX1.5/VX2 (page 3.3.3)
