VX150 TO VX2 TROUBLESHOOTING MANUAL WIRING INFORMATION
VERSION 2.0 2023-04-20 PAGE 3.3.3
Table 3.3.5: Cable Information, VX1.5/VX2
Cable Description
Nautel
Part #
Source
Mate
Destination
Mate
*A14W1 Cable Assembly, Flat IDC, 0.100" pitch, 14 cond, 8.50" UA322 A1J12 A14J1
W1 Cable Assembly, Flat IDC, 0.050" Tiger Eye, 10cond, 2.25" UA295 A3J4 A12J4
W2 Cable Assembly, Flat IDC, 0.050" Tiger Eye, 16 cond, 2.25" UA296 A3J7 A6J3
W3 Cable Assembly, Flat IDC, 0.050" Tiger Eye, 20cond, 3.25" UA297 A1J11 A3J8
W4 Cable Assembly, Flat IDC, 0.050" Tiger Eye, 20 cond, 11.00" UA298 A3J3 A5J2
W5 Cable Assembly, Flat IDC, 0.050" Tiger Eye, 10cond, 8.75" UA300 A3J10 A4J2
W6 Cable Assembly, Flat IDC, 0.100" pitch, 20 cond,2.00" UA301 A5J3 U1CN1
W7
Cable, Coax, SRC 316, MCX(M) RA to MCX(M) Straight, 5.0"
UA307 A1J10 A6J1
W8
Cable, Coax, SRC 316, MCX(M) RA to MCX(M) Straight, 5.0"
UA307 A6J2 A3J6
W9
Cable, Coax, SRC 316, MCX(M) RA to MCX(M) Straight, 5.0"
UA307 A3J5 A12J1
W10
Cable, Coax, SRC 316, MCX(M) RA to BNC(F) Bulkhead, 10.0"
UA309 A11J1 RF MONITOR
W11 Cable, Coax, SRC 316, MCX(M) RA to MCX(M)RA, 12.0" UA310 A11J3 A3J9
W12 Cable, Coax, SRC 316, MCX(M) RA to MCX(M)RA, 16.0" UA311 A11J2 A1J9
W13
Cable, Coax, SRC 316, MCX(M) RA to MCX(M) Straight, 10.0"
UA313 A12J2 A7J1
W14
Cable, Coax, SRC 316, MCX(M) RA to MCX(M) Straight, 10.0"
UA313 A12J3 A8J1
W15 Cable, SATA, 0.5m, Straight F to Straight F, Shielded UA316 A1J14 A5J1
W16 Cable Assembly, Flat IDC, 0.050" Tiger Eye,30 cond, 2.00" UA318 A1J17 A2J5
NOTE: * - denotes used only when Orban audio processor card is installed
