StockCode:
NARF80A
Page 27 of 51
Description
:
Final Assy, VX1.5/2,
Component Lvl, StockCode Reference DesignationDescription
NAPH15
01
2-Way Splitter Pwb Assy A12
CCFS04
02
Cap,SMT,Ceramic,0.01uF,10%,50V,X7R,0603 C01, C02
CS81
02
Capacitor, SMT, Porcelain,24pF 500V, 2% C05
CS89
02
Capacitor, SMT, Porcelain,27pF 500V, 2% C07
CT53
02
Capacitor,SMT,Ceramic,0.001uF, 50V,10% C03, C04
JT188
02
Conn, Jack, MCX, 50Ohm, Gold, Vert, SMT J01, J02, J03
JU91
02
Conn, Header, Shrouded, 0.050" 10pos, Dual Row, Go J04
LS68
02
Inductor, SMT, 56nH, 2%, 3A, 4.2mm H x 4.95mm L L01
RAD38
02
Resistor, SMT, MF, 12.1K Ohms, 1% 1/4W R01, R02
RFFS38
02
Resistor,SMT,MF,1000ohms,1%, 1/10W,0603 R03, R04
RT57
02
Resistor, SMT, AIN, 100 ohms, 2%, 30W, 3725 R05
NAPI187A
01
System Interface PWB Assy A03
CCJ01
02
Cap,SMT,Ceramic,1000pF,10%, 50V,X7R,0402 C02, C04, C11, C12, C14, C15, C53, C81, C82, C86
CCJ02
02
Cap,SMT,Ceramic,0.01uF,10%, 50V,X7R,0402 C19, C22, C47, C65, C83, C84
CCJ03
02
Cap,SMT,Ceramic,0.1uF,10%, 50V,X7R,0402
C01, C03, C05, C13, C16, C17, C18, C20, C21, C24, C25, C26,
C27, C28, C29, C30,, C31, C32, C37, C38, C40, C41, C42, C43
C44, C45, C46, C48, C50, C51, C54, C55, C56, C57, C58, C59
,
C61, C63, C64, C66, C68, C69, C71, C72, C74, C77, C78, C79,
C80
CCJ04
02
Cap,SMT,Ceramic,1uF,10%, 25V,X5R,0402 C08, C09, C23, C39, C73, C85
CCJ06
02
Cap,SMT,Ceramic,4.7uF,10%, 25V,X7R,0805 C52, C60, C62, C75
CCJ10
02
Cap,SMT,Ceramic,18pF,1%, 50V,C0G,0402 C67
CCJ18
02
Cap,SMT,Ceramic,22uF,20%, 25V,X5R,0805 C70, C76
CCJ20
02
Cap,SMT,Ceramic,15pF,1%, 50V,C0G,0402 C33, C35
CT112
02
Cap, SMT, Elect, Alum Polymer, 100uF, +/- 20%, 25V C06, C07, C10
CT65
02
Cap, SMT, Ceramic, 6.8pF, 50V, +/-0.25pF, 1206 C49
HAJ66
02
Terminal, SMT, Test Point, PWB TP03, TP14
JF47
02
Conn, Header,Square Post,Gold, Dual,40-pin J12
JQ16
02
Conn, Header, SIP, 12 Pin Breakaway, 10 Ctr J11
JR77
02
Terminal Block, 2 Pos, 300V, 13A, 28-14AWG, Spring TB02
JR89
02
Terminal Block, 4 Pos, 300V, 26 - 20AWG, Spring C TB01
JT188
02
Conn, Jack, MCX, 50Ohm, Gold, Vert, SMT J05, J06, J09
JU131
02
Conn, Header, Shrouded, 4-pos, 3.00mm, Dual Row, G J01, J02
