Nautel VX150 - Page 109

StockCode:
NARF80A
Page 29 of 51
Description
:
Final Assy, VX1.5/2,
Component Lvl, StockCode Reference DesignationDescription
UDTS05
02
IC, SMT, RS-232 Transceiver, 3.3V, SO-16 U04
ULAS01
02
IC,SMT,Opamp,Quad,Single Supply,SOIC-14 U01
UT157
02
IC, SMT, DC-DC Conv, Buck, Adj, 2A, 4.5-28Vin, SOT U06
UT158
02
IC, SMT, Amp, Current Sense, Precision, 50V/V, SOT U05
UW207
02
Attenuator, SMT, 20dB, 50 ohm, 0.5W, DC to 8 GHz U09
UX161
02
IC, SMT, Micro, 128K, 8K SRAM, 3.3V, TQFP-100 U02
UX191
02
IC, SMT, RMS RF Power detector , 3.3V, 40MHz-10GHz U10
UX83
02
IC,SMT,2.5V Reference,0.1%,SOT -23-6 U03
XFPS14
02
Crystal,SMT,Fund,32.768kHz, 10ppm,12.5pF,50kOhm,-4 Y01
NAPI188
01
Power Supply Interface PWB Assy - 3.5kW A04
CCFS09
02
Cap,SMT,Ceramic,0.47uF,10%,25V,X7R,0805 C02
CCFS52
02
Cap, SMT, Ceramic, 0.1uF, 10%, 25V X7R, 0603
C01, C03, C07, C09, C10, C11, C12, C13, C15, C16, C17, C18,
C19, C20, C21, C22, C23, C24
CCFS73
02
Cap, SMT, Ceramic, 1uF, 10%, 16V, X5R, 0603 C05, C14
CX33
02
Cap,SMT,Ceramic,4.7uF,20%,10V, X5R,1206 C06
HAC122
02
1 Pin Screw Terminal, Power Tap M3 Surface Mount E01, E02, E03, E04
HAJ66
02
Terminal, SMT, Test Point, PWB TP2
JA137
02
Conn, PwrBlade, 3ACP+4P+24S, RA PCB, CP3500 Mate J01
JR78
02
Terminal Block, 3 Pos, 300V, 13A, 28-14AWG, Spring TB1
JT202
02
Conn, Recept, AC, 250VAC, 20A, PWB Mount J03
JU91
02
Conn, Header, Shrouded, 0.050" 10pos, Dual Row, Go J02
LS23
02
Choke, SMT, Common Mode, 7000 ohm, 700mA L01
RFCS04
02
Resistor, SMT, 0.002 ohms, 1%, 5W R22, R28
RFFS01
02
Resistor,SMT,MF,0.0ohms,Jumper ,0603 R32, R34, R36, R37
RFFS26
02
Resistor, SMT, MF, 100ohms, 1%, 1/10W, 0603 R09, R14
RFFS27
02
Resistor, SMT, MF, 121ohms, 1%, 1/10W, 0603 R04, R05, R06, R07
RFFS34
02
Resistor,SMT,MF,475ohms,1%, 1/10W,0603 R03, R10
RFFS38
02
Resistor,SMT,MF,1000ohms,1%, 1/10W,0603 R29, R30
RFFS40
02
Resistor,SMT,MF,1500ohms,1%, 1/10W,0603 R25, R26
RFFS42
02
Resistor,SMT,MF,2210ohms,1%,1/10W,0603 R08, R16, R17, R19
RFFS43
02
Resistor, SMT, MF, 2740ohms, 1%, 1/10W, 0603 R11
RFFS46
02
Resistor, SMT, MF, 4750ohms, 1%, 1/10W, 0603 R13
