RESPONDING TO ALARMS VX150 TO VX2 TROUBLESHOOTING MANUAL
PAGE 3.1.30 VERSION 2.0 2023-04-20
SCA1 Analog Left Low Audio The Analog Left audio input level has fallen
below the user configured low audio
threshold for longer than the user configured
timeout.
The Analog Left audio input must be
configured as a SCA source in the active
preset for this alarm to trigger.
The SCA 1 Low Alarm must be enabled in the
active preset for this alarm to occur.
This alarm will clear immediately when the
Analog Left input level has increased above
the configured threshold.
Performing an alarm reset will clear this alarm
and reset the timeout.
Check the audio feed connected to the
Analog Left input. The most likely cause
of this alarm is an interruption in audio
distribution to the transmitter.
Verify that the threshold level
programmed in the active preset is below
the normal input level by checking the
Analog Left meter.
Verify that the configured timeout is long
enough to cover any silence or dips in
signal level.
SCA2 AES2 Left Low Audio The AES2 Left audio input level has fallen
below the user configured low audio
threshold for longer than the user configured
timeout.
The AES2 input must be configured as a SCA
source in the active preset for this alarm to
trigger.
The SCA 2 Low Alarm must be enabled in the
active preset for this alarm to occur.
This alarm will clear immediately when the
AES2 left input level has increased above the
configured threshold.
Performing an alarm reset will clear this alarm
and reset the timeout.
Check the audio feed connected to the
AES2 input. The most likely cause of this
alarm is an interruption in audio
distribution to the transmitter.
Verify that the threshold level
programmed in the active preset is below
the normal input level by checking the
AES2 Left meter.
Verify that the configured timeout is long
enough to cover any silence or dips in
signal level.
SCA2 Analog Right Low Audio The Analog Right audio input level has fallen
below the user configured low audio
threshold for longer than the user configured
timeout.
The Analog Right audio input must be
configured as a SCA source in the active
preset for this alarm to trigger.
The SCA 2 Low Alarm must be enabled in the
active preset for this alarm to occur.
This alarm will clear immediately when the
Analog Right input level has increased above
the configured threshold.
Performing an alarm reset will clear this alarm
and reset the timeout.
Check the audio feed connected to the
Analog Right input. The most likely cause
of this alarm is an interruption in audio
distribution to the transmitter.
Verify that the threshold level
programmed in the active preset is below
the normal input level by checking the
Analog Right meter.
Verify that the configured timeout is long
enough to cover any silence or dips in
signal level.
Alarm Name Trigger Conditions Clear Conditions Troubleshooting
