Nautel VX150 - Page 85

StockCode:
NARF79A
Page 5 of 51
Description
:
Final Assy, VX1,
Component Lvl, StockCode Reference DesignationDescription
CCJ21
02
Cap,SMT,Ceramic,0.22uF,10%, 25V,X5R,0402 C116, C125, C432, C434, C437
CCJ22
02
Cap,SMT,Ceramic,4700pF,10%, 50V,X7R,0402 C383
CCJ23
02
Cap,SMT,Ceramic,0.022uF,10%, 50V,X7R,0402
C104, C113, C354, C358, C362, C365, C366, C368, C372,
C374, C376
CCJ24
02
Cap,SMT,Ceramic,0.047uF,10%, 50V,X7R,0402 C105, C112, C118, C367, C371
CCJ25
02
Cap,SMT,Ceramic,1000pF,1%,50V, C0G/NP0,0402 C015
CTFS03
02
Cap,SMT,Tantalum,10uF,10%,35V, 2917 C124
CTFS04
02
Cap,SMT,Tantalum,100uF,10%,10V,2917 C010, C138, C142, C151,
HAJ66
02
Terminal , S M T, Test Poi n t , P W B TP10, TP22
JM49
02
Conn, Socket, 1xMag RJ45 + 2x USB-A J03
JN60
02
Conn, Receptacle, Right Angle, SMA, PWB Mount J08
JQ15
02
Conn, Post Shunt, 2 Pos, .10 C entreline E01, E02
JQ16
02
Conn, Header, SIP, 12 Pin Breakaway, 10 Ctr XE01, XE02
JQ56
02
Conn,SMT,Plug,SATA,Signal,R/A PWB J14
JQ77
02
Conn, SMT, Header, Ribbon Cabl e, 14 pin J12
JQ94
02
CONN, SMT, SD CARD, PUSH-PUSH, R/A XU63
JR51
02
Terminal Block,2-pos,PWB Mount J07
JT121
02
Conn, Dual, D-Sub, F/M, 9 pin, Rt. Angle, PWB J06
JT188
02
Conn, Jack, MCX, 50Ohm, Gold, Vert, SMT J09, J10
JT203
02
Conn, Micro USB 2.0 Type B, Right Angle, SMT J15
JT204
02
Conn, BNC, Dual Stacked, Isolated J04
JT77
02
Connector,Modular,Dual,RJ-45 Jack Rt Agl, PWB J05
JT87
02
Conn,3-pin,PWB Mount, Fem, XLR J01, J02
JU85
02
Conn, Header, Shrouded, 0.050" 30pos, Dual Row, Go J17
JU91
02
Conn, Header, Shrouded, 0.050" 10pos, Dual Row, Go J19
JU92
02
Conn, SMT, Header, 10-pin, 0.1", Dual Row, Gold J18
JU96
02
Conn, Header, Shrouded, 0.050" 20pos, Dual Row, Go J11, J13, J16
LA72
02
Bead, Ferrite, SMT, 120 Ohm at 100MHz, 1.3A, 0402 L37, L38, L40, L44, L45, L46, L48, L49
LA73
02
Bead, Ferrite, SMT, 1 kOhm at 100MHz, 350mA, 0402 L39, L42, L43
LA74
02
Bead, Ferrite, SMT, 1.5 kOhm at 100MHz, 500mA,0603 L52
LCFS01
02
Inductor, SMT, Choke, 600ohms, 2A, 0805
L04, L05, L07, L10, L12, L18, L20, L21, L22, L23, L26, L27,
L30, L31, L32, L34, L35, L41, L50,, L53, L54, L55, L56, L57
LCFS02
02
Inductor, SMT, Choke, 2000 ohm s, 80mA, 0805 L01, L03, L06, L09, L14, L15, L16, L19, L33, L36, L47, L51
LCFS04
02
Bead, Ferrite SMT, 200 ohms @ 1MHz, 100mA, 1206 L13
LS60
02
Inductor, SMT, 22uH, 4A RMS, Shielded, Pwr L24
