Nautel VX150 - Page 87

StockCode:
NARF79A
Page 7 of 51
Description
:
Final Assy, VX1,
Component Lvl, StockCode Reference DesignationDescription
RAF44
02
Resistor SMT MF 3320 Ohm 1% 1/16W 0402 R381
RAF45
02
Resistor SMT MF 3920 Ohm 1% 1/16W 0402 R041, R061, R404
RAF46
02
Resistor SMT MF 4750 Ohm 1% 1/16W 0402 R165, R175, R184, R188, R334, R359
RAF47
02
Resistor SMT MF 5620 Ohm 1% 1/16W 0402 R192, R193
RAF50
02
Resistor SMT MF 10.0K Ohm 1% 1/16W 0402
R011, R015, R018, R019, R020, R022, R023, R028, R029,
R030, R036, R042, R043, R045, R046, R047,, R048, R050,
R053, R054, R055, R056, R057, R063, R064, R065, R066,
R067, R077, R082, R083, R084,, R089, R090, R101, R102,
R105, R107, R111, R112, R113, R114, R117, R118, R119,
R126, R128, R146,, R148, R153, R154, R157, R160, R162,
R173, R180, R182, R183, R185, R189, R195, R198, R201,
R205,, R210, R215, R216, R220, R223, R224, R226, R228,
R229, R231, R233, R235, R236, R242, R243, R246,, R248,
R249, R250, R251, R252, R261, R269, R271, R273, R277,
R278, R279, R282, R287, R290, R302,, R308, R313, R314,
R315, R335, R337, R342, R345, R346, R347, R348, R351,
R352, R353, R356, R360,, R378, R388, R411, R412, R413,
R414
RAF53
02
Resistor SMT MF 18.2K Ohm 1% 1/16W 0402 R071
RAF56
02
Resistor SMT MF 33.2K Ohm 1% 1/16W 0402 R070
RAF59
02
Resistor SMT MF 56.2K Ohm 1% 1/16W 0402 R073
RAF62
02
Resistor SMT MF 100K Ohm 1% 1/16W 0402 R031, R044, R132, R291, R292, R304, R305, R387
RAF63
02
Resistor SMT MF 121K Ohm 1% 1/16W 0402 R069
RAF74
02
Resistor SMT MF 1.00M Ohm 1% 1/16W 0402 R167
RAF82
02
Resistor SMT MF 49.9 Ohm 1% 1/16W 0402
R001, R002, R003, R004, R007, R008, R009, R010, R027,
R032, R127, R151, R169, R170, R179, R354,, R355, R362
RAF85
02
Resistor SMT MF 13.3K Ohm 1% 1/16W 0402
R035, R122, R190, R194, R254, R257, R258, R262, R274,
R306, R316, R333
RAF86
02
Resistor SMT MF 41.2K Ohm 1% 1/16W 0402 R255, R256, R265, R307, R312, R317
RAF88
02
Resistor SMT MF 243 Ohm 1% 1/16W 0402 R329, R331
RAF89
02
Resistor SMT MF 2000 Ohm 1% 1/16W 0402 R222, R232
RAF91
02
Resistor SMT MF 9530 Ohm 1% 1/16W 0402 R368
RFFS01
02
Resistor,SMT,MF,0.0ohms,Jumper ,0603 R086, R384
RFFS23
02
Resistor, SMT, MF, 56.2ohms, 1%, 1/10W, 0603 R211, R212, R239, R240
