Nautilus E514c - Assembly Instructions; Step 7: Connect Cables & Attach Console

12
7. Connect Cables and Attach Console to Frame Assembly
NOTICE : Align the clips on the cable connectors and make sure the connectors lock. Do not crimp the cables.
* Hardware is pre-installed on Console and not on Hardware Card.
*
#2
X4
