Nautilus E514c - Hardware and Tools; Hardware Components Guide; Tools Required for Assembly

7
Tools
Included Not Included
#2
6 mm
Item Qty
Description
Item Qty
Description
A 4 Wide Washer, M8 J 2 Leveler Washer
B 32 Lock Washer, M8 K 2 Leveler Screw
C 32 Washer, M8 L 4 Round Cover
D 4 HexHeadBolt,M8x20LThreadLock M 2 Cotter Pin
E 4 ButtonHeadHexScrew,M8x25L
Thread Lock
N 2 Wave Washer
F 2 PhillipsHeadScrew,M5x20L O 4 Lock Washer, M8 Black
G 8 ButtonHeadHexScrew,M8x20L P 6 Cover
H 2 ButtonHeadHexScrew,M8x20L
Thread Lock
Q 6 ButtonHeadHexScrew,M8x25L
I 12 ButtonHeadHexScrew,M8x15L R 6 FlatHeadHexScrew,M8x25LThread
Lock
(recommended)
HARdWARE / TOOLS
A B C D E F G
H
I
J LK
M N
O
Q
R
