Nautilus E514c User Manual

6
Adecalhasbeenappliedtoallright(“R ”)andleft(“L ”)partstoassistwithassembly.
Item Qty
Description
Item Qty
Description
1 1 Frame 11 1 Left Leg
2 2 Pedal Mount Plate 12 1 Right Handlebar Arm
3 1 Rear Stabilizer 13 1 Left Handlebar Arm
4 1 Front Stabilizer 14 1 Lower Left Handlebar Arm
5 1 Console Mast 15 1 Lower Right Handlebar Arm
6 1 Transport Handle 16 1 Static Handlebar
7 2 Rail 17 1 Console
8 1 Right Pedal 18 1 AC Adapter
9 1 Left Pedal 19 1 Arm Pivot Rod
10 1 Right Leg 20 1 MP3 Cord (not shown)
pARTS
7
6
3
4
1
5
16
17
11
10
14
15
19
8
2
13
12
18
9
