Nautilus E514c - Assembly Instructions; Step 10: Attach Pedals and Arms

15
10. Attach Pedals to Rails and Lower Handlebar Arms
NOTICE : Be sure the key on the Cotter Pin engages the Lower Handlebar Arm.
X2
