4-20 BenchMike Pro Instruction Handbook: Setup
4.9.3 Fixture Sample Report
The Fixture Sample Report is designed for use with automated part positioning fixtures, such as the Auto-Rotating
Chuck Fixture. This report is automatically printed one time at the end of the fixture measurement cycle. Note that
there is no header for this report.
NOTE: A maximum of 31 characters is permitted in the Title (shown as “Your Information Here”) line.
0.351379 0.356977 0.362025 0.359710 0.350075 0.353630 0.357084
0.354713
MAX: 0.362025 MIN: 0.350075 DIFF: 0.011950 AVG: 0.355699 SD: 0.0040568
READINGS: 8
