2. Setting up
Express5800/R320e-E4, R320e-M4 Installation Guide (Linux)
40
Chapter 1 Installing Operating System
2.5 Network Setting
Network setting is described here.
Important Be sure to use the vndctl command if setting the IP address, subnet mask, and
default gateway. For details, see Chapter 2 (2. Network Duplexing) in "Maintenance
Guide".
2.5.1
Overview of network setting
The network duplexing is configured as a pair of the CPU/IO module 0 and CPU/IO module 1 and the network
interface of the PCI slot corresponding to each module. The network interface is named according to the naming
rule described below.
PCI slot and network interface name
PCI slot Port CPU/IO module 0 CPU/IO module 1 Slot number of the vndctl
command
1G LAN connector #1 eth100600 eth110600 1
#2 eth100601 eth110601 2
10G LAN
connector
#1 eth101200 eth111200 3
#2 eth101201 eth111201 4
PCI slot 1 #1 eth100100 eth110100 5
#2 eth100101 eth110101 6
PCI slot 2 #1 eth100200 eth110200 7
#2 eth100201 eth110201 8
PCI slot 3* #1 eth100300 eth110300 9
#2 eth100301 eth110301 10
PCI slot 4* #1 eth100400 eth110400 11
#2 eth100401 eth110401 12
* For R320e-E4, 10G LAN connector, PCI slot 3, and PCI slot 4 do not exist.
