2. Setting up
Express5800/R320e-E4, R320e-M4 Installation Guide (Linux)
41
Chapter 1 Installing Operating System
2.5.2
Network setting method
An example of setting the following items is described here.
Slot number of the vndctl command：1
IP address ：192.168.0.10
Subnet mask ：255.255.255.0
Default gateway ：192.168.0.1
1. Install the LAN cable.
2. Log in to the server as the root user. If you login with graphical mode, select [Others...] to login.
3. Execute the following command to disable the coupled interface.
# vndctl down 1
Note For the 1G LAN connector, the coupled interface that sets eth100600 and eth110600
tobond0 and eth100601 and eth110601 tobond1 is enabled during the OS set up.
4. Execute the following command to set the network. Items marked with * must be input by a user.
The default gateway can be omitted by pressing the <ENTER> key without inputting.
# vndctl config 1
[Virtual Network Setting]
*Boot Protocol? [none/dhcp/bootp] none
*IP address? 192.168.0.10
*Netmask? 255.255.255.0
*Default gateway (IP)? 192.168.0.1
*Are you sure to set it? [y/n] y
NAME=bond0
DEVICE=bond0
TYPE=Bond
ONBOOT=yes
BOOTPROTO=none
BONDING_OPTS="miimon=100 mode=active-backup"
IPADDR=192.168.0.10
NETMASK=255.255.255.0
GATEWAY=192.168.0.1
5. Execute the following command to enable the coupled interface.
# vndctl up 1
6. Execute the following command to check that IP address appears in bond0 and Status of eth100600
and eth110600 is DUPLEX.
# vndctl status
--Virtual Network Status--
BondingDevice Slot Status InetAddress RXErrors TXErrors Collisions
bond0 1 ONLINE 192.168.0.10 0 0 0
bond1 2 ONLINE - 0 0 0
Slot RealDevice Status Interface LinkState LinkSpeed
1 top eth100600 DUPLEX UP LINK 1000Mb/s-FD
bottom eth110600 DUPLEX UP LINK 1000Mb/s-FD
2 top eth100601 DUPLEX UP LINK 1000Mb/s-FD
bottom eth110601 DUPLEX UP LINK 1000Mb/s-FD
