NEC MultiSync WD551 - Specifications - WD551

English-38
Specications - WD551
Product Specications
LCD Module Pixel Pitch:
Resolution:
Color:
Brightness(max):
Contrast Ratio:
Viewing Angle:
0.315 mm x 0.315 mm
UHD 3840 x 2160 (pixels)
(R + G + B design)
1.07 G(8 bits + FRC)
min: 350 cd/m
2
typ: 400 cd/m
2
Brightness with AG Glass
1200:1
178° (Horizontal&Vertical)
Frequency Horizontal:
Vertical:
min:30 kHz
typ: 67.5 kHz [Normal mode] / 135 kHZ [WCD mode]
max:135 kHz
min:23 Hz [Normal mode] / 50 Hz [WCD mode]
typ:30 Hz [Normal mode] / 60 HZ [WCD mode]
max:76 Hz
Pixel Clock 25.0-600 MHz (DisplayPort by USB)
25.0-600 MHz (HDMI)
Viewable Size 1209.6 (H) x 680.4 (V)
Input Signal
DisplayPort USB-C1 Connector Digital RGB, YUV DisplayPort V1.4 (3840 x 2160 @ 60Hz, HDCP2.2/1.3)
USB-C2 Connector Digital RGB, YUV DisplayPort V1.4 (3840 x 2160 @ 60Hz, HDCP2.2/1.3)
HDMI HDMI Connector Digital RGB, YUV HDMI (3840 x 2160 @ 60Hz, HDCP2.2/1.4)
AUDIO
AUDIO Input USB-C1 Connector Digitai Audio PCM 32, 44.1, 48 KHz (16/20bit), 2ch
USB-C2 Connector Digitai Audio PCM 32, 44.1, 48 KHz (16/20bit), 2ch
HDMI Connector Digital Audio PCM 32, 44.1, 48 KHz (16/20bit), 2ch
AUDIO Output N/A
Speaker Output Internal Speaker 12 W + 12 W (Sterreo) + 15 W (Subwoofer)
Control RS-232C IN:
LAN:
9 Pin D-sub [DTE type]
RJ45 10BASE-T/100BASE-TX x 1
USB Hub USB3.0 Side port (Type-A) x 2
Side port (Type-B) x 1
Power Supply 1.7 - 4.2 A @ AC 100 - 240 V 50/60 Hz
1.7 A @ 240 V
4.2 A @ 100 V
Power Consumption (Maximum) 371 W
Operational Environment Temperature:
Humidity:
Altitude:
0~40°C / 32~104°F
10~90%
5000 m (16404 ft)
Storage Environment Temperature:
Humidity:
-20~60°C / -4~140°F
90% (Over 40°C / below 60%)
Dimension 1266.0 x 856.8 x 86.5 mm / 49.84 x 33.73 x 3.41 inches
Weight 31.5 kg (69.45 lbs)
VESA compatible mounting interface 400 mm x 200 mm (M8, 4 Holes) (not VESA)
Power Management N/A
Protective glass Material:
Thickness:
Surface treatment:
Transparency:
Haze:
Surface hardness:
Impact resistance:
Tempered glass
3.0 mm
Anti-Glare+Anti-Fingerprint coating
≥88%
4~10%
7H
Ball drop test: 500 g steel ball, 1.2 m High
