NEC NC1000C - Setting Up Your Projector - Connector Details

36
Setting Up Your Projector
China
Plug Cable Connector
GB2099
RVV 300/500 GB17465.1
Connector
Dimensions of the connector of the power cable are shown below.
7
+ 0.5
- 0
28
+0
-
0.9
20
+0
-
0.7
6.0
+ 0.5
- 0
2.5
+ 0.5 -
0
2.5
+ 0.5
- 0
8 ±
0.2
13 ±0.2
Unit: mm
R3.5 min
20 min
