56
Projector Adjustment and Connecting
3-6. Adjusting the Lens
After attaching the lens unit, check that the lens type is set correctly. Furthermore, if you have attached a lens unit that supports the
lens memory function, always execute calibration before adjusting the lens. After this, display the test pattern and adjust the screen
size, focus and screen position with the lens unit.
Preparation:
Enable the service personnel menu (page 66).
3-6-1. Set the Lens Type
1
Press the MENU button on the control panel.
“Title Select” is displayed in the menu.
2
Press the LEFT/RIGHT button to display “Conguration” and press the DOWN button.
3
Press the LEFT/RIGHT button to display “Installation” and press the DOWN button.
4
Press the LEFT/RIGHT button to display “Lens Type” and press the DOWN button.
5
Press the LEFT/RIGHT button to select the type of lens attached to the projector.
When shipped from the factory, it is set to [Without Sensor].
Without Sensor Select when using a lens unit that does not support the lens memory function.
With Sensor Select when using a lens unit that supports the lens memory function.
6
Press the ENTER button.
(*) is displayed to the selected item.
7
Press the EXIT button several times.
The projector exits the menu and goes back to the regular screen.
