6. Appendix
6-6. Specications
Model name NC900C-A
Projection method 3 chip DLP Cinema® method
0.69-inch DC2K chip
Panel resolution 2048 x 1080
Lamp type 350W AC lamp
Screen sizes 7 m to 8.1 m @14ft-L / Screen Gain 1.3, Max. 9.5 m @14ft-L / Screen Gain 1.8 (Depends on setup conditions)
Contrast ratio 1600:1 with DCI specified color representation
Lens adjustment function Motorized lens shift (vertical/horizontal), motorized zoom, motorized focus, douser
Signal input ports When shipped from factory: Empty
(for mounting optional components) (Note 1)
External Control RS-232C (D-sub 9pin) x 1
GPIO port (D-sub 37 pin) x 1
Service terminal (stereo mini jack) x 1
3D CTL (D-sub 15 pin) x 1
USB (Type A) x 1
Interlock port x 1
Ethernet port (G-bit RJ-45) x 1
Power supply voltage AC 100 to 130 V, 50/60 Hz single phase
AC 200 to 240 V, 50/60 Hz single phase
Input current 10.3 to 7.9 A (100 to 130 V)
5.1 to 4.3 A (200 to 240 V)
Power consumption 1023 W (100 to 130 V) (Note 2)
985 W (200 to 240 V) (Note 2)
Cooling method Cooling air system (includes dust filter)
Noise level Less than 52 dB
Installation Orientation: Desktop/front, Desktop/rear, Ceiling/front, Ceiling/rear
Net weight 44 kg (Excluding lens)
Dimensions 621 mm (W) x 798 mm (D) x 314 mm (H) (Does not include protruding portions, includes foot.)
Environment Operating temperature: 10 to 35°C
Operating humidity: 10 to 85% (non-condensing)
Storage temperature: -10 to 50°C
Storage humidity: 10 to 85% (non-condensing)
Operating altitude: 0 to 3000m/9800 feet (1600m/5500 feet to 3000m/9800 feet: Set “Fan Speed Mode” to “High
Altitude”)
Regulations <Safety> <EMC>
USA UL60950-1 2nd Edition FCC Part15 Class A
Canada CSA60950-1 2nd Edition ICES-003 Class A
Europe EN60950-1 2nd Edition EN55022 Class A, EN55024, EN61000-3-2/-3-3
Russia IEC60950-1 2nd Edition, GOST-R, Hygenic EN55022 Class A, EN55024, EN61000-3-2/-3-3
Oceania IEC60950-1 2nd Edition AS/NZS CISPR. 22 Class A
Asia IEC60950-1 2nd Edition EN55022 Class A, EN55024, EN61000-3-2/-3-3
Korea K60950-1 K00022 Class A, K00024
Saudi Arabia SASO EN55022 Class A, EN55024, EN61000-3-2/-3-3
Japan J60950-1 VCCI Class A, JIS C 61000-3-2, J55022 Class-A
(Note 1) The video input slots are empty when the device is shipped. The optional Signal Input Board is available as separate
optional products.
(Note 2) The value is typical.
* Note that these specifications and design can change without prior notice.
