78
6. Appendix
6-7. Power Cable
NOTE
Ask your dealer for the power cable to select and purchase.
Power Cable Electrical Specication
The projector is equipped with an IEC60320 C19 connector to connect an AC power supply cable. Ensure that the AC power
cables that connect the connectors built into the projector to the AC power mains have the current capacities as shown below.
Power supply voltage Projector input current Power cable current capacity
AC 100–130V 10.3 to 7.9A 125V 15A or higher
250V 15A or higher
AC 200–240V 5.1 to 4.3A 250V 15A or higher
Type of Power Cable
Cable
Plug
Connector
Use plugs, cables, and connectors that are suitable for the regulations of the country of installation, as shown in the following
table.
NOTE
For users in North America
Use a power cable no longer than 4.5m/14.76 ft according to National Electrical Code.
Germany
Plug Cable Connector
CEE 7
H05VV-F 3G1.5 IEC 320 C19
USA
Plug Cable Connector
NEMA 5-15P
SJT 3 x AWG 14 IEC 320 C19
To Next Page
