42
4. Using Menus
4-2. Table of adjustment menus
Menus in parentheses are menus for our service personnel. Normally, these menus cannot be used.
Main menu Submenu Description
Reference
page
Title Select “Title Memory Name” Selects the title of the signal to be projected. 43
TEST Pattern Selects the test pattern to be projected. 43
Configuration Lamp Setup Adjust Adjusts lamp brightness. 44
Lamp Mode Selects the lamp to use. 44
Lens Control Lens Position Adjusts the position of the projected screen. 45
Focus Zoom Adjusts the size and focus of the projected screen. 45
Reset (FactoryDefault) Returns the settings to their default values. Selects between preset but-
tons and titles only, LAN settings only and all settings.
-
Lamp Usage Initializes the usage time of the lamp. 46
Filter Usage Initializes the usage time of the air filter. 46
(Fan Usage) Initializes the usage time of the fan. -
(Douser Count) Resets the number of times the douser has been used. -
(Setup) Douser Setup Sets the douser open/close state. -
Panel Key Lock Locks the buttons on the projector’s control panel so that they cannot be
operated.
-
Auto Key Lock Enables or disables Auto Key Lock. -
3D Connector Sets the signal input terminal for a 3D image system (3D terminal or
GPI/O terminal).
Sets the video input port for 3D video systems.
-
Unlit Mode Sets the projector operation when the lamp does not turn on. -
Off Timer Sets the time until the projector power is turned off automatically. -
Filter Message Sets the time to display the message indicating the air filter replacement
cycle.
-
Silent Mode Selects whether to use the status indicator, buzzer, indicators on the
control panel and backlight.
-
(Installation) Option Slot Configures the device installed in slot A (only when the projector is in
standby mode).
-
Orientation Sets the projection method and cooling fan operating mode. -
Lens Center Moves the lens shift position to the center. -
Baudrate Sets the PC control connector (RS-232) data transmission speed (bps). -
Date/Time Sets the date and time on the projector. -
New Router Setup Sets the router with the default settings when the router built-in the
projector has been replaced.
-
Fan Speed Mode Sets the cooling fan operating mode. -
(Title Setup) Preset Button Preset Button 1–16 Sets the title to be assigned to the preset buttons (<1> to <8> buttons). 47
Information Lamp Output Displays the lamp output setting. 47
Voltage Displays the lamp voltage value. 47
Preset Button Preset Button 1–16 Displays the titles which are assigned to the preset buttons (<1> to <8>
buttons).
47
Usage Displays information related to projector usage. 48
Error Code Displays the currently occurring error. 48
Version System Displays the model name and various version information about the
projector.
48
SIB Displays the model and version of the signal input board (SIB). 49
IMB Displays the vendor name and version information about the media
block (IMB).
49
Slave Displays the slave firmware version of the projector. 49
Ballast Displays the ballast firmware version of the projector. 49
IP Address System Displays the IP address of the projector. 49
Setup Date Displays the date when the projector was set up (starting date of the
warranty period).
50
Option Status Displays the link status of the device mounted in slot A and projector. 50
