ROI-S04488 OPERATION
3-51
Step
Procedure
For 1+1 System
Alarm and Status
8 Press the “3” for 1+0 (or “2” for 1+1) key and “Enter” key, then,
following alarm items are displayed,
For 1+0 System
Notes: 1. “*” : indicates alarm condition.
2. “–” : indicates normal condition.
3. Monitoring of alarm/status displayed on the
LCT depend on system configuration.
4. CHANNEL USAGE ERROR 1-16 is displayed
only when “Channel usage error (report)” is
selected to “report” and Main channel usage is
set to used.
5. WS CHANNEL USAGE ERROR is not
displayed when “Channel usage error
(report)” is selected to “not report” .
Monitoring
1. Monitoring voltage
2. Alarm/Status
3. Inventory
00. Menu
99. Exit
Select item No. :
3. Monitoring of alarm/status 1/2
IDU
INPUT LOSS 1-16 (alarm:**** ---- ---- ----)
CHANNEL USAGE ERROR 1-16 (alarm:**** ---- ---- ----)
AIS RCVD 1-16 (alarm:---- ---- ---- ----)
AIS SEND 1-16 (alarm:**** ---- ---- ----)
OUTPUT LOSS 1-16 (alarm:---- ---- ---- ----)
LAN INTFC ALM (alarm:-)
WS INPUT LOSS (alarm:-)
WS CHANNEL USAGE ERROR (alarm:-)
WS AIS RCVD (alarm:-)
WS AIS SEND (alarm:-)
WS OUTPUT LOSS (alarm:-)
TX CLK LOSS (alarm:-)
FSYNC ALM (alarm:*)
HIGH BER ALM (alarm:*)
LOW BER ALM (alarm:*)
BER ALM (alarm:*)
Press any key to continue …
To Next Page
