OPERATION ROI-S04488
3-52
Step
Procedure
Notes: 1. “*” : indicates alarm condition.
2. “–” : indicates normal condition.
3. “5ch” : RF channel number is displayed.
For 1+1 System
3. Monitoring of alarm/status 2/2
MOD ALM (alarm:-)
DEM ALM (alarm:*)
OPR ALM (alarm:*)
ODU
TX PWR ALM (alarm:-)
RX LEV ALM (alarm:-)
APC1 ALM (alarm:-)
APC2 ALM (alarm:-)
IF INPUT ALM (alarm:-)
MUTE (off)
TX/RX FREQ CH (5ch)
Press any key to continue …
2. Monitoring of alarm/status 1/2
IDU
INPUT LOSS 1-16 (alarm:---- ---- ---- ****)
CHANNEL USAGE ERROR 1-16 (alarm:**** ---- ---- ----)
AIS RCVD 1-16 (alarm:---- ---- ---- ----)
AIS SEND 1-16 (alarm:---- ---- ---- ----)
OUTPUT LOSS 1-16 (alarm:---- ---- ---- ----)
LAN INTFC ALM (alarm:-)
WS INPUT LOSS (alarm:-)
WS CHANNEL USAGE ERROR (alarm:-)
WS AIS RCVD (alarm:-)
WS AIS SEND (alarm:-)
WS OUTPUT LOSS (alarm:-)
TX CLK LOSS(No.1/No.2) (alarm:-/-)
RX CLK LOSS(No.1/No.2) (alarm:-/-)
FSYNC ALM(No.1/No.2) (alarm:-/-)
HIGH BER ALM(No.1/No.2) (alarm:-/-)
LOW BER ALM(No.1/No.2) (alarm:-/-)
BER ALM(No.1/No.2) (alarm:-/-)
Press any key to continue …
