ROI-S04488 OPERATION
3-53
Step
Procedure
Notes: 1. “∗” : indicates alarm condition.
2. “−” : indicates normal condition.
3. Monitoring of alarm/status displayed on the LCT
depend on system configuration.
4. CHANNEL USAGE ERROR 1-16 is displayed only
when “Channel usage error (report)” is selected to
“report” and Main channel usage is set to used.
5. WS CHANNEL USAGE ERROR is not displayed
when “Channel usage error (report)” is selected to
“not report” .
Notes: 1. “∗” indication indicates alarm condition.
2. “−” indication indicates normal condition.
3. “0 ch” indication shows setting channel number.
4. Monitoring of alarm/status displayed on the LCT
depend on system configuration.
5. The LCT display shows Hot standby system. In Twin
path system, it is displayed as follows:
TX/RX FREQ. CH No.1 (0 ch)
TX/RX FREQ. CH No.2 (0 ch)
9 Press the “Esc” key to go back to the Monitoring menu,
2. Monitoring of alarm/status 2/2
MOD ALM(No.1/No.2) (alarm:-/-)
DEM ALM(No.1/No.2) (alarm:-/*)
OPR ALM(No.1/No.2) (alarm:-/*)
MDP CPU ALM(No.1/No.2) (alarm:-/*)
ODU
TX PWR ALM(No.1/No.2) (alarm:-/-)
RX LEV ALM(No.1/No.2) (alarm:-/-)
APC1 ALM(No.1/No.2) (alarm:-/-)
APC2 ALM(No.1/No.2) (alarm:-/-)
IF INPUT ALM(No.1/No.2) (alarm:-/-)
MUTE No.1(off)
MUTE No.2(on)
TX/RX FREQ CH (5 ch)
Press any key to continue …
