135
8. Appendix
SDI
Signal Resolution(dots) AspectRatio RefreshRate(Hz)
SD-SDI(480i) 720/1440 × 480 4:3/16:9 60
SD-SDI(576i) 720/1440 × 576 4:3/16:9 60
HD-SDI(1035i) 1920 × 1035 16 : 9 60
HD-SDI(1080i) 1920 × 1080 16 : 9 50/60
HD-SDI(1080p) 1920 × 1080 16 : 9 24pSF
HD-SDI(1080p) 1920 × 1080 16 : 9 24/25/30
HD-SDI(720p) 1280 × 720 16 : 9 24/25/30/50/60
3G-SDI(1080p) 1920 × 1080 16 : 9 50/60
3G-SDI(1080p) 1920 × 1080 16 : 9 24/25/30
3G-SDI(1080p) 1920 × 1080 16 : 9 24pSF
3G-SDI(1080i) 1920 × 1080 16 : 9 50/60
QuadSDI 3840 × 2160 16 : 9 24/25/30/50/60
QuadSDI 4096 × 2160 *
2
17 : 9 24/25/30/50/60
*1 HDBaseTdoesnotsupportthissignal.
*2 Native resolution
• Uponshipment,theprojectorissetforsignalswithstandarddisplayresolutionsandfrequencies,butadjustmentsmayberequired
dependingonthetypeofcomputer.
