1. Introduction
Connection terminals
4
1
11
10
9
87
56
2
3
1. REMOTETerminal[REMOTE](StereoMini)
 Usethisjackforwiredremotecontroloftheprojector
usingacommerciallyavailableremotecablewith⌀3.5
stereomini-plug(withoutresistance).
 Connecttheprojectorandthesuppliedremotecontrol
usingacommerciallyavailablewiredremotecontrol
cable.
(→
page15)
2. LANport[LAN](RJ-45)
 Theportforcontrollingthe projectorfromaPCvia
anetwork.ConnecttheprojectorandthePCwitha
commerciallyavailableEthernetcable(10/100Base-
T).
3. USBport[USB](typeA)
 Theportfortheprojectormaintenance.
4. PCcontrolterminal[RS-232](D-sub9P)
 TheterminalforoperatingtheprojectorfromaPCvia
anRS-232Corforservicepersonneltosetdatafor
theprojector.ConnecttheprojectorandthePCwith
acommerciallyavailableRS-232Cstraightcable.
5. 3Dterminal[3D](D-sub15P)
 (notavailableonthisseriesofprojectors)
6. Externalcontrolterminal[GPI/O](D-sub37P)
 The terminal for externallycontrolling theprojector.
(→page141)
7. HDMI1IN/HDMI2INTerminal[HDMIIN1/IN2]
(TypeA)
(→page121)
8. DisplayPort1IN/DisplayPort2INTerminal
[DisplayPortIN1/IN2]
(→page121)
9. HDBaseTPort[EthernetHDBaseT](RJ-45)
(→page121)
10.SDI1/SDI2/SDI3/SDI4INTerminal[3G/HD/SD-SDI
IN1/IN2/IN3/IN4](BNC)
(→page121)
11. SLOT
 Expansion slots forinstallingoptional boardssold
separately.Aplatetopluguptheopeningisattached
whentheunitisrstshippedfromthefactory.
