❺ Portrait projection (vertical orientation)
Ifyouinstalltheprojectorverticallyyoucanprojectscreensfromyour
computer and other sources in portrait orientation.
• BesuretoinstallthedevicewiththesidewheretheConnectiontermi-
nalsandControls/IndicatorPanelarelocatedfacingthetop.
• Angletodisplayallthescreenssuchastheon-screenmenucanbe
changedbythemenu[SETUP]→[MENU(2)]→[MENUANGLE].
Precautionsduringinstallation
• Donotsimplysettheprojectorverticallyontheoororonatable.Theprojectormayfallover,resultingininjury,
damageormalfunction.Alsotheintakeventmaybecomeblockedcausingtheunit’sinternaltemperaturetorise
resultinginmalfunctionandriskofre.
• Forportraitinstallationtheintakeventsmustbeinstalledatthetopandbottom.Toensureairowtothebottom
intakevent,aracktosupporttheunitisnecessary.Pleasehireaninstallationserviceprovider(forafee)to
makeacustomportraitprojectionstand.
• Wheninstalledinportraitorientationtheprojectorcanbetiltedforwardorbackward
 withinarangeof±10°.Tiltingtheprojectorforwardorbackwardoutsideofthisrange,ortiltingittotheleftorto
therightcouldcauseittomalfunction.
• Toensureairow,maintain60cm/23.6"ofspacebetweentheintake
vent and the installation surface.
 (NOTE)Intheguretotherightthereisplentyofspacebehind,above,
and on either side of the projector unit.
60 cm/23.6" or greater
