1. Introduction
Bottom of the projector
1
1
2
2
3
3
4
4
1. Handle(4locations)
 Handlesformovingtheprojector.
2. Leveladjusters(in4positions)
 Intheordinaryinstallation,youcanadjusttheprojectorinclinationat4positions.
3. Handle(4locations)
 Handlesformovingtheprojector.
4. Eyeboltmountingholes(4locations)
 Theseareusedtosuspendtheprojectorformovementandinstallationpurposes.
 Wheninstallingusingeyebolts,haveyourdistributorinstalltheunit.
