LOADBY
SIGNAL
OFF Ifinputsignalisswitched,thelenswillnotshifttothelesshift,zoomandfocusval-
uesfortheselected[PROFILE]number.
ON Ifinputsignalisswitched,thelenswillshifttothevaluesfortheselected[PROFILE]
number.
Ifnoadjustedvalueshavebeenstoredto[LENSMEMORY],thelenswillapply
[REF.LENSMEMORY]adjustedvalues.Alternatively,ifnoadjustedvalueshave
beenstoredto[REF.LENSMEMORY],thelenswillstayunmoved.
FORCED
MUTE
OFF Notturnofftheimageduringlesshift.
ON Turnofftheimageduringlesshift.
•SHUTTERSETTINGS
POWERON
SHUTTER
OPEN Whenthepoweristurnedon,thelensshutteropensandthepictureisprojected.
CLOSE Thelensshutterremainsclosedevenwhenthepoweristurnedon.PresstheSHUT-
TERbuttontoopentheshutterandprojectthepicture.
PICTURE
MUTESHUT-
TER
OPEN Thelensshutterremainsopenwhenthepicturedisappearse.g.whentheinputterminal
is switched and so on.
CLOSE
Thelensshuttercloseswhenthepicturedisappearse.g.whentheinputterminalis
switched and so on.
FADETIME IN SethowlongthelightwilltaketofadeinaftertheSHUTTERbuttonispressed.
Thetimecanbesetfrom0to10secondsinincrementsof1second.
OUT SethowlongthelightwilltaketofadeoutaftertheSHUTTERbuttonispressed.
Thetimecanbesetfrom0to10secondsinincrementsof1second.
⓬ Storing Changes for Lens Shift, Zoom, and Focus [LENS
MEMORY]
ThisfunctionservestostoretheadjustedvalueswhenusingtheLENSSHIFT,ZOOMandFOCUSbuttonsofthepro-
jector.Adjustedvaluescanbeappliedtothesignalyouselected.Thiswilleliminatetheneedtoadjustlensshift,focus,
andzoomatthetimeofsourceselection.Therearetwowaystosaveadjustedvaluesforlensshift,zoom,andfocus.
Functionname Description page
REF.LENSMEMORY Adjustedvaluescommontoallinputsignals.Atthetimeofinstallation,
twokindsofadjustedvaluescanbestored.
Ifnoadjustedvalueshavebeensavedto[LENSMEMORY],thelens
willapply[REF.LENSMEMORY]adjustedvalues.
→page98
LENSMEMORY Adjustedvaluesforeachinputsignal.
Usetheadjustedvaluesforthesignalwithadifferentaspectratioor
resolution.Theadjustedvaluescanbeappliedatthetimeofsource
selection.
→page89
NOTE:
• Besuretocarryout[LENSCALIBRATION]afterinstallingthelensunitL4K-11ZM/L4K-15ZM/L4K-20ZM.
 Ifyouneedtoreplacethelensunit,contactyourdistributorandhavethemdoitforyou.
