19
2. Projecting an Image (Basic Operation)
4. Pull the band to hold the power cable.
Pulling the knob in the arrow direction allows you to adjust
the band position.
Pull the top and bottom bands by keeping their balance.
Once the band position is adjusted, release the knob to
lock.
Knob
Knob
Thiscompletes the attachment of the power cable stopper.
Removing the power cable from the power cable stopper
1. Pull the knoboftheclamperand loosen the band.
2. Pull the knob and slide the clamper away from the
power plug.
CAUTION
•
Theprojectormaybecomehottemporarily when the power is turned off or if theACpowerisdisconnected while
the projectorisprojecting.Takecarewhenhandlingtheprojector.
