4. Using On-Screen Menu
TOP MENU SUB MENU FACTORY DEFAULT SELECTIONS
DISPLAY
LENS LOCK OFF OFF / ON
LENS CONTROL
ZOOM
FOCUS
SHIFT
LENS MEMORY
MEMORY 1 STORE / LOAD / RESET
MEMORY 2 STORE / LOAD / RESET
MEMORY 3 STORE / LOAD / RESET
MEMORY 4 STORE / LOAD / RESET
MEMORY 5 STORE / LOAD / RESET
MEMORY 6 STORE / LOAD / RESET
MEMORY 7 STORE / LOAD / RESET
MEMORY 8 STORE / LOAD / RESET
MEMORY 9 STORE / LOAD / RESET
MEMORY 10 STORE / LOAD / RESET
CENTER LENS
DIGITAL ZOOM
DIGITAL ZOOM 0
DIGITAL PAN 0
DIGITAL SCAN 0
RESET
GEOMETRIC CORRECTION
KEYSTONE
HORIZONTAL 0 -600–600
VERTICAL 0 -400–400
ROTATION 0 -10–10
RESET
ROTATION
ROTATION 0 -100–100
RESET
PINCUSHION / BARREL
H PINCUSHION / BARREL 0
-150 (PINCUSHION) <= ( H,V ) <= 300
(BARREL)
V PINCUSHION / BARREL 0
-150 (PINCUSHION) <= ( H,V ) <= 300
(BARREL)
H KEYSTONE 0
HORIZONTAL -60–60
V KEYSTONE 0 VERTICAL -40–40
ROTATION 0 -10–10
RESET
ARC
TOP 0 -150–150
BOTTOM 0 -150–150
LEFT 0 -150–150
RIGHT 0 -150–150
RESET
TOP LEFT CORNER
HORIZONTAL 0 -192 < H < 192
VERTICAL 0 -120 < V < 120
RESET
TOP RIGHT CORNER
HORIZONTAL 0 -192 < H < 192
VERTICAL 0 -120 < V < 120
RESET
BOTTOM LEFT CORNER
HORIZONTAL 0 -192 < H < 192
VERTICAL 0 -120 < V < 120
RESET
BOTTOM RIGHT CORNER
HORIZONTAL 0 -192 < H < 192
VERTICAL 0 -120 < V < 120
RESET
BLANKING
TOP 0 0–360
BOTTOM 0 0–360
LEFT 0 0–534
RIGHT 0 0–534
RESET
EDGE BLENDING
MODE OFF OFF / ON
MARKER OFF OFF / ON
RANGE
TOP 0 0, 100–500
BOTTOM 0 0, 100
–500
LEFT 0 0, 100–500
RIGHT 0 0, 100–500
BLACK LEVEL
TOP 0 0–32
BOTTOM 0 0–32
LEFT 0 0–32
RIGHT 0 0–32
ALL 0
RED 0 0–32
GREEN 0 0–32
BLUE 0 0–32
RESET
SCREEN TYPE 16:10 16:10 / 16:9 / 4:3
