7-3. Specifications
Model name PX2000UL
Method Single DLP
®
chip
Specications of main parts
DMD panel Size 0.96" (24.4 mm) (aspect ratio: 16:10)
Pixels
(*1)
2,304,000 (1920 dots × 1200 lines)
Projection lenses
Please refer to the specications of option lens (→ page 80)
Light source Laser Diode
Optical device Optical isolation by dichroic mirror, combining by dichroic prism
Light output
(*2)
LIGHT
MODE
NORMAL 18,000 lm
(*3)
/ 19,000 lm (Center)
BOOST 19,000 lm
(*3)
/ 20,000 lm (Center)
Contrast ratio
(*2)
(all white/all black) 10,000:1 with dynamic contrast
Screen size (throw distance)
Please refer to the “Throw distance and screen size” (→ page 72)
Color reproducibility 10-bit color processing (approx. 1.07 billion colors)
Scanning frequency Horizontal Digital: 15 kHz, 24 to 153 kHz, conforming to VESA standards
Vertical Digital: 24, 25, 30, 48 Hz, 50 to 85 Hz, 100, 120 Hz conforming to VESA standards
Main adjustment functions Power zoom, power focus, power lens shift, input signal switching (HDMI 1/HDMI 2/
COMPUTER/BNC/DVI-D/DisplayPort/SDI/HDBaseT), auto image adjustment, picture
maginication, power on/standby, on-screen display/selection, etc.
Max. display resolution (horizontal ×
vertical)
Analog: 1920 × 1200 (WUXGA)
Digital: 2560 × 1600 (WQXGA) (by scaling technology)
Input signal R, G, B, H, V RGB: 0.7 Vp-p/75 Ω
H/V Sync: 4.0 Vp-p/TTL
Sync on G: 1.0 Vp-p/75 Ω (With Sync)
Input/output terminals
HDMI Video input HDMI
®
Connector type A × 2
Deep Color (color depth): 8-/10-/12-bit compatible
Colorimetry: RGB, YCbCr444, YCbCr422, YCbCr420, REC2020, REC709, REC601
Supports HDCP
(*4)
DisplayPort Video input DisplayPort × 2
Data rate: 5.4 Gbps/2.7 Gbps/1.62 Gbps
No. lanes: 1 lane/2 lanes/4 lanes
Deep Color (color depth): 8-/10-/12-bit compatible
Colorimetry: RGB, YCbCr444, YCbCr422, REC709, REC601
Supports HDCP
(*4)
HDBaseT/LAN
port
Video input RJ-45 × 1, 10BASE-T/100BASE-TX
Deep Color (color depth): 8-/10-/12-bit compatible
Colorimetry: RGB, YCbCr444, YCbCr422, YCbCr420, REC709, REC601
Supports HDCP
(*4)
SDI (3D/HD/SD) Video input BNC × 1
Input signals: SMPTE259M, SMPTE292M, SMPTE424M
Colorimetry: RGB, YCbCr444, YCbCr422, REC709, REC601
Video output BNC × 1
COMPUTER Video input Mini D-Sub 15 Pin × 1, BNC × 5
Video output Mini D-Sub 15 Pin × 1
DVI-D Video input DVI-D × 1
3D SYNC IN Video input BNC × 1, synchronized signal input for 3D use
1920 × 1200 RB 120 Hz, Frame Sequential
3D SYNC OUT Video output
BNC × 1, synchronized signal output for 3D use
TRIGGER 1/2 Video output Stereo mini jack × 2
PC CONTROL terminal D-Sub 9-pin × 1, 9600 bps
REMOTE terminal Stereo mini jack × 1
Usage environment
(*5)
Operating temperature: 41 to 104°F (5 to 40°C)
Operating humidity: 20 to 80% (with no condensation)
Storage temperature: 14 to 140°F (-10 to 60°C)
Storage humidity: 20 to 80% (with no condensation)
Operating altitude: 0 to 4200 m/13779 feet
Power supply 200-240 V AC, 50/60Hz
Power con-
sumption
LIGHT
MODE
BOOST 1922 W
NORMAL 1779 W
ECO 1461 W
STAND-
BY
POWER
ON 4.8 W
OFF 0.4 W
