uPASS Access | installation guide
4/
1 Introduction
The uPASS Access is an ultra-small UHF RFID reader for handsfree door access.
Based passive UHF technology, people are identified up to 2 meters (
6.5 feet).
Typical applications include hands-free door access in hospitals, office buildings, gated communities, care homes
and universities.
The uPASS Access is ideal for door post mounting at a height of about 1.5 meters (
5 feet). It can be installed directly
onto a wall next to a door, without requiring additional mounting accessories. The reader is IP65 rated, so it can be
used indoors as well as outdoors. Installation cable 5 meter (
15 feet) is included.
The uPASS Access supports a variety of industry-standard communication interfaces and protocols, such as RS485,
Wiegand, Magstripe (clock & data) and the Open Supervised Device Protocol (OSDP). This enables seamless integration
into any existing or new access control or parking system.
1.1 Firmware versions
The uPASS Access reader supports different firmware versions. Below an overview of the available firmware versions
and their key features.
Standard firmware
• STANDARD ASCII (CR/LF) protocol.
• Wiegand.
• Magstripe ISO7811/2 (clock & data).
OSDP firmware
• OSDP according to the SIA OSDP v2.1.7 standard.
• Secure channel protocol supported.
• LED and buzzer control through OSDP commands.
• General purpose input (3x) and outputs (2x).
OSDP (Open Supervised Device Protocol) is an access control communications standard developed by the Security
Industry Association (SIA). The OSDP protocol specification can be obtained from the website;
www.securityindustry.org/industry-standards/open-supervised-device-protocol
.
