uPASS Access | installation guide
19/
33
3.6 Nedap antenna interface
The Nedap antenna interface is used to connect the uPASS Access to NEDAP AEOS access control hardware such as
the AP1001. Instead of proximity antenna the uPASS Access can be connected.
Connections
PURPLE
Nedap antenna interface. RFMOD antenna modulation (ANT/HF+)
BLACK
Nedap antenna interface. Ground, shield (ANT/HF-).
SHIELD
Shield connected to DC-ground. Connect to metal case of the external device.
OSDP firmware
The OSDP firmware does not support the Nedap antenna interface.
Notes
• Nedap-XS formatted UHF tags are required to use the Nedap antenna interface!
• Use RG58U coax cable when extending the wiring beyond the standard 5 meter cable.
• Maximum cable length 100 meters (
350 feet).
