Nedap uPASS Access - Outputs

uPASS Access | installation guide
17/
33
3.4 Outputs
The uPASS Access reader has 2 digital outputs. The function of the digital outputs is dependent upon the installed
firmware version. See description below.
STANDARD firmware
The outputs are used for Wiegand or Magstripe communication. See respectively chapters 3.2.3 or 3.2.4.
OSDP firmware
The outputs are general purpose outputs. The outputs are open-collector and can be used to activate an external relay.
Use the OSDP_OUT command to control the output state. The outputs allow for direct activation and deactivation plus
timed operation (OSDP output control compliance level 3). The permanent command is volatile (does not transcend
power cycles)
When the status of an output changes the reader will send an output status change report message OSDP_OSTATR.
Connections
GRAY
Output 0 / Data-0 / CLK
PINK
Output 1 / Data-1 / DAT
GROUND
Ground
SHIELD
Shield connected to DC-ground. Connect to metal case of the external device.
Output ratings
Type Open collector (internal weak 5V pull-up resistor)
Max. voltage +24 VDC
Max. current 200 mA
