Nederman E-PAK 500 - Filter Replacement

E-PAK 500EN
32
Caution! Risk of equipment damage.
Never operate the unit without a plastic bag.
9.3 Replacingthemainlterandlterbags
WARNING! Risk of electric shock.
Always disconnect the supply voltage with the maintenance switch before any service, whether
mechanical or electrical. Always lock the maintenance switch in the off position.
WARNING! Risk of personal injuries.
Ensure that there is no vacuum present in the system during service.
WARNING! Risk of personal injuries.
Always disconnect the compressed air supply before any service.
WARNING! Risk of personal injuries.
Use proper lifting and protective equipment.
9.3.1 Mainlter
Replace the whole main lter after approximately 6,000 hours of operation and at least every
3 years.
To replace the main lter:
1. Remove the main lter according to Figure 16.
2. Put the old lter in a large plastic bag, or wrap it in plastic foil, see Figure 13.
NOTE! Avoid dust spreading.
3. Install the new main lter.
Caution! Risk of equipment damage.
It is important that no dust, objects or debris are allowed to fall down into the inlet of the side
channel fan.
9.3.2 Individuallterbags
Replacing individual lter bags is possible, but we recommend replacing the whole lter
package, including the lter panel and locking rings, as it is quicker and causes less spreading
of dust.
Individual lter bags which have been damaged may be replaced, see Figure 14. Use a robust
screwdriver to detach the plastic locking ring.
The coiled spring may be kept for use with the new lter bag, but a new locking ring is to be
used to secure the new lter, see Figure 15.
NOTE! Never re-use an old locking ring!
9.4 Fan service
WARNING! Risk of personal injuries.
Use proper lifting and protective equipment.
Caution! Risk of equipment damage
It is important that no dust, objects or debris are allowed to fall down into the inlet of the side
channel fan.
