FlexPAK 800/1000EN
38
If the piston does not fall down, the piston may not evacuate properly. If the incoming
compressed air is disconnected, the piston should fall down allowing the lid to close the
lter top opening.
8 ATEX Duct Isolaon Valve sengs
This is for ATEX units with the Duct Isolaon Valve and Duct Isolaon Damper.
8.1 Flush Cycle sengs
One of the already occupied outputs is used to control the Duct Closing Damper. Output
DO12, is used to control Duct Isolaon Damper; it is the same output that controls Flush
Valve 2.
If the Duct Isolaon Damper is installed, it reduces the ush funcon to only one ush
valve, Flush Valve 1.
The soware can sll control both ush valves but in this soware, but the Flush Valve 2
seng is changed.
8.1.1 FlushCy1(T) (Timer)
Control Flush Valve 1, has output DO5 Terminal 73 and 74.
This funcon is sll in standard operaon and sengs. Default seng T10 = 10 seconds.
8.1.2 FlushCy2(T) (Timer) (Dual Funcon)
Control Flush Valve 2 or Duct Isolaon Damper, has output DO12 Terminal 64 and 65.
This funcon is sll in standard operaon, default seng is changed and adapt to the Duct
Isolaon Damper seng.
If you use DO12 to a Duct Isolaon Damper, there is no need to set FlushCy2(T). T=0 is the
default.
1. Duct Isolaon Damper seng
– T=0s (Default seng)
2. Flush Valve seng
– T=10s
8.2 Tuning Duct Isolaon Damper sequence
Use gure ‘3’ as a reference when reading this tuning descripon.
Normally the default seng a is proper starng point to use and test the FlexPak system.
If a problem occurs such as an unintended acvaon of the Duct Isolaon safety valve, it is
me to consider tuning the Duct Isolaon Damper sequence.
8.2.1 FCDely(T) Parameter
Filter cleaning delay me is used to ensure that the Duct Isolaon Damper is closed before
the rst lter cleaning (FC) pulse.
To set FCDely(T) parameter, it is necessary to know how long me it takes for Duct Closing
Damper to go from Open to Closed.
Test the me it takes for the Duct Closing Damper to close at the default Vacuum set point
for the system.
