WALL INSTALLATION

MOUNTING

130 mm

Fixing

0DUN WKH XSSHU À[LQJ SRLQW RQ WKH ZDOO

and set the wall plug and screw leaving

the head protruding.

2- Unscrew the screw at the bottom of

the product, and remove the terminal

cover.

μ 1A

250V~

1- Remove the front cover. +DQJ WKH KRXVLQJ RQ WKH XSSHU À[LQJ

SRLQW DQG PDUN WKH ORZHU À[LQJ SRLQW

through the hole in the housing socket.

Set the lower wall plug.

Distance between

the attachment

points: 130 mm.

μ 1A

250V~

5- Fasten the

housing on

to the wall by

À[LQJWKHORZHU

screw.

6- Fit the terminal

cover on to the

cabinet and

tighten the screw

at the bottom of

the product.

μ 1A

250V~

7- Fit the front cover on to the device.
