Neomitis SR - Pump Station Installation; Installation on a Din Rail

MOUNTING
PUMP STATION INSTALLATION
INSTALLATION ON A DIN RAIL
<RX FDQ XVH WKH WZR À[LQJ KROH SDLU DW WKH
XSSHUEDFNVLGHRIWKHFRQWUROOHUWRÀ[LWZKHQ
it is inserted in a pump station.
Use self-tapping screws.
35
1- Mounting
Hang the controller on the upper edge of
the DIN rail.
Then push the controller at the bottom, the
solar controller will lock automatically on
the rail.
2- Unmounting
First take off the terminal cover.
Draw the hook towards the bottom with a
VFUHZGULYHUWRXQORFNWKHUDLOÀ[LQJ
Meanwhile take off the solar controller.
CLICK
~
