Neomitis SR - Symbols and Abbreviations Lexicon

OVERVIEW
SYMBOLS AND ABBREVIATIONS LEXICON
Symbol Solid display Flashing display
Mode selectors
Solar collector
T1 sensor temperature (solar collector)
T1 sensor selection
T2 sensor temperature (lower section of
the cylinder or the pool)
T2 sensor selection
T3 sensor temperature
T3 sensor selection
T4 sensor temperature
T4 sensor selection
Anti-freeze function
Setting mode
Setting in progress
3-way valve
Valve selection
Rate per cent
9
Symbol
