TECHNICAL SPECIFICATIONS
Inputs / Outputs Description Name
4 temperature inputs PT1000 sensor type T1, T2, T3, T4
1 synchronization input Input driven by a free-voltage contact from
a time switch
(closed when low-tariff period running)
E1
Solar pump control output, rated load Semi-conductor 200W max, mains live
switch (0,1A min output current)
R1
2nd control output, rated load Relay 2A max, mains live switch R2
3rd control output, rated load Relay 1A max @ 250V, voltage-free R3
Power supply voltage 230-240V~, -10% +5%, 50Hz Mains
Environment Description
Safety Insulation: Class II,
Protection rating: IP20,
Pollution degree: 2,
Rated pulse voltage: 4KV
Operation temperature range 0 to +40°C
Storage temperature range -20°C to +70°C
Maximum humidity rate 85% RH non condensing @ 25°C
Standards EN60730-1
EN60730-2-9
Accessories Description Name
1 x High temperature probe
STAPT15HTA
PT1000 probe, -30°C to 200°C,
1,5 metres, red cord
T1 (T4)
2 x Standard temperature probe
STAPT25NTA
PT1000 probe, -15°C to 105°C,
2,5 metres, black cord
T2, T3 (T4)
Extension cable On request T1 (T4)
The symbol, on the product means that you must dispose of it at the
end of its life at a special recycling point, in accordance with the European
Directive WEEE 2002/96/EC. If you are replacing it, you can also return it to
the retailer from which you buy the replacement equipment. Indeed, the
product should not be disposed of with standard household waste. Recycling
products enables us to protect the environment and to use less natural resources.
Compliance declaration: we hereby declare under our sole responsibility that the products
described in these instructions comply with all the main requirements of the Low Voltage
2006/95/EC, CEM 2004/108/EC and RoHs 2011/65/EC directives and were manufactured
XVLQJSURFHVVHVZKLFKDUHFHUWLÀHG,62
86
