N58 Hardware User Guide

Chapter 4 Module Pins

SPI interface

SPI_CLK

Clock signal

Leave this pin floating

if it is not used.

SPI_MISO

Output from

the slave

device, and

input from

the master

device

Leave this pin floating

if it is not used.

SPI_MOSI

Input from

the slave

device, and

output from

the master

device

Leave this pin floating

if it is not used.

SPI_CS_N

Chip select

signal of the

slave device

Leave this pin floating

if it is not used.

GPIO interface

GPIO_0

GPIO

Leave this pin floating

if it is not used.

GPIO_2

GPIO

Leave this pin floating

if it is not used.

GPIO_3

GPIO

Leave this pin floating

if it is not used.

Audio SPK interface

SPK_P

Speaker

output

positive

SPK_N

Speaker

output

negative

Audio MIC interface

MIC_P

Microphone

input

positive

MIC_N

Microphone

input

negative
