Figure 5-6 Reference design of module startup controlled by button

N58 Module

VBAT

1kΩ

20kΩ

Main Chip

ESD

PWRKEY_N

470Ω

Figure 5-7 Reference design of module startup controlled by MCU

47kΩ

4.7kΩ

USER_ON

N58 Module

VBAT

1kΩ

20kΩ

Main Chip

PWRKEY_N
