N58 Hardware User Guide
Chapter 4 Module Pins
Copyright © Neoway Technology Co., Ltd. All rights reserved.
27
KEYOUT3
130
DO
Key output
-
-
KEYOUT2
131
DO
Key output
-
-
KEYOUT1
132
DO
Key output
-
-
KEYOUT0
133
DO
Key output
-
-
KEYIN1
134
DI
Key input
-
-
KEYIN2
135
DI
Key input
-
-
KEYIN3
136
DI
Key input
-
-
USB_BOOT
48
DI
Forcible
download
control
P3
Connect this pin to the
1.8 V power supply by
using a 10 kΩ pull-up
resistor before the
module power-on, and
the module enters the
USB download mode.
Leave this pin floating
if it is not used.
RESERVED
9, 10, 34, 107-111,
116-120, 124-127,
148-154
Reserved
pins
-
Used for future
function expansion or
functions that are not
open to users. There
may be more than one
pin named
RESERVED, but it
does not mean that the
RESERVED pins have
the same function or
definition. Be sure to
keep the RESERVED
pins floating.
 Sub-models of the N58 module without GNSS:
Pin 9 and pin 10 of the N58 module can be used for the UART4 interface (pin 9 is used for UART4_TXD,
pin 10 is used for UART4_RXD, and the interface level is 1.8 V). Pin 89 of the N58 module can be used for
the ADC2 interface (ADC2 interface characteristics are the same as ADC1 interface characteristics ).
 Sub-models of the N58 module with GNSS:
Pin 9 and pin 10 of the N58 module are RESERVED pins and must be kept floating. Pin 89 is the 1PPS pin.
For details, see section 5.6.9 "1PPS."
